Flat Panel Detector
1. Detector Type: TFT Full-Field Amorphous Silicon Flat Panel Detector
2. Detector Panel Size: 430 mm x 430 mm
3. Effective Imaging Area: 17×17 inches
4. Detector Pixel Matrix: 3072×3072
5. Pixel Pitch: 146 μm
6. Detector Spatial Resolution: 3.4 LP/MM
7. Pixel Bit Depth: 16Bit
8. Image Acquisition and Transmission Time: 3s
High-Frequency High-Voltage Generator
1. Maximum Output Power: 32 kW
2. Input Power Supply: 220VAC single-phase
3. Output Voltage: 40～150kV
4. Tube Current Range: 10～320mA
5. Exposure Time Range: 1ms-10000ms
6. mAs Range: 0.1mAs-250mAs
7. Supports AEC, APR automatic exposure
8. Fault Self-Diagnosis, Display
X-ray Tube Assembly
1. Focal Spot Design: 0.6mm/1.2mm
2. Nominal Power: 21kW/46kW (50Hz)
3. Maximum KV: 150kV
4. Anode Target Angle: 12°4.
Column
1.Column Rotation Angle: ±90°, error ±2°
2. Vertical Movement Range of X-ray Tube Assembly: 1259cm, error ±2cm
3. Tube and Collimator rotate left and right in the horizontal direction greater than ±90°,error ±2cm
Grid and Collimator
1. Grid Material: Aluminum grid
2. Size: 18×18 inches (48×48cm)
3. Grid Ratio: 10:1
4. Lines per inch: 215C
5. Grid Focal Distance: 1000MM
6. With light field, multi-leaf DR-specific collimator
Image Acquisition/Processing and Diagnostic Workstation Software Functions
1. Chinese interface, standard DICOM3.0 images
2. Image acquisition workstation functions: adjust or preset window width/window level,
local automatic window width/window level, preset window width/window level, positive and negative image flipping, image flipping, rotation, image zooming and roaming, image interpolation edge enhancement, local zooming, restore original image annotation, text/number annotation, image marking, ruler line segment measurement, square/circular measurement, arbitrary shape measurement, angle measurement, automatic electronic cropping, image stitching, exposure index (Exposure Index) acquisition and display
3. Special image acquisition control software package, special site protocol processing software package
4. Patient management, image acquisition, image processing (image correction, image flipping, USM sharpening, image filtering), image observation (providing image observation tools, measurement tools)
5. Image printing: DICOM printing, paper printing, manual selection printing of displayed images, single-key selection marked image printing, selection of different printing devices, film format and number of prints, print queue control, stop/start pre-set
6. User personalization settings: display format and layout, default value settings, toolbar settings, site protocol enhanced filters
7. Image display: Display configuration supports 1920×1080, high-definition display
Workstation
1. CPU: Intel i7, 3GHz or above
2. Host Memory: ≥8GB DDR3 1600 high-speed memory
3. Hard Disk: Large capacity high-speed hard disk 1T/7200rpm
4. Workstation Monitor: IPS LCD Monitor
5. Communication Network Card and Network Interface: 1000M network card, 1000M network interface, Jumbo Frames: 9K
6. DICOM3.0 Interface
7. Windows 10 64 bit SP1 (Professional Edition or higher)
